G 7000 PRO HM PUR

Gluing machines

G 7000 PRO HM PUR

HM PUR – ROLL APPLICATION – GLUING LINE

HM-PUR lamination technology instead of water-based spreading application, ideally designed for "less consumption" of glue and application in up to 25 gr/m².

The G7000 PRO HM-PUR is the top-in-class machine for high volumes and low glue consumption.

It works perfectly with foam, fiber, coconut, springs, felt, non-woven, etc. Includes n. 2 spreading ROLLS, machine equipped with hydraulic oil pump for heating rolls.

  •  Dimensions : 11,00×3,80xH3,60mt
  • Weight : 14.500 Kg
  • Installed power : 12 Kw
  •  Machine power supply : 400 V + N + E – 50/60 Hz
  •  Compressed air : 6/8 BAR
  • Productivity: 50mt/min
